无机械接触
|
VART Serles |
VART150 |
VART200 |
VART260 |
|
|
Width |
150 mm |
200 mm |
260 mm |
|
|
Tabletop Diameter |
100 mm |
145 mm |
200 mm |
|
|
Height |
135 mm |
165 mm |
185 mm |
|
|
Aperture |
20 mm |
30 mm |
50 mm |
|
|
Total Travel |
360°Continuous |
|||
|
Bus Voltage |
UP to 320VDC |
|||
|
Fundamental Encoder Resolution |
11840 lines/rev |
18000 lines/rev |
23600 lines/rev |
|
|
Max Speed |
1200 rpm |
800 rpm |
600 rpm |
|
|
Accuracy |
±2 arc sec |
|||
|
Repeatability(Bi-Directional) |
＜1 arc sec |
|||
|
Max Load |
Axial |
20kg |
40kg |
70kg |
|
Radial |
3kg |
6kg |
10kg |
|
|
Tilt |
3.5 N-m |
8 N-m |
18 N-m |
|
|
Axial Error Motion |
＜100nm |
|||
|
Radial Error Motion |
＜150nm |
|||
|
Tilt Error Motion |
＜5.0 arc sec |
|||
|
Axial Error Motion |
＜20 nm |
|||
|
Radial Error Motion |
＜20 nm |
|||
|
Tilt Error Motion |
＜0.04 arc-sec |
|||
|
Operating Pressure |
0.5 MPa ± 0.05 MPa |
|||
|
Air Consumption |
＜2 SCFM |
|||
|
Inertia |
Unloaded |
2200 kg-mm2 |
13600 kg-mm2 |
46000 kg-mm2 |
|
Total Mass |
6.5kg |
14.5kg |
27kg |
|
|
Material |
Black Aluminum Body |
|||
